ClearViz Video Laryngoscopes
The SourceMark ClearViz™ Video Laryngoscope is an advanced airway visualization system designed to improve intubation success, enhance clinician confidence, and support better patient outcomes. Featuring a high-resolution camera, powerful LED illumination, anti-fog lens technology, and flexible viewing angles, ClearViz provides clear, real-time visualization to help clinicians manage routine and difficult airway procedures with greater precision.
Product Details
- 0-megapixel CMOS camera technology
- High-intensity LED illumination
- Rotating 3.5-inch high-resolution display
- Built-in 32 GB storage
- Available with a comprehensive selection of single-use and channeled blades
Product Features
High-Resolution Airway Visualization
A 2.0-megapixel CMOS camera and powerful LED illumination provide clear, detailed airway images to help clinicians visualize anatomical structures and support accurate intubation.
Flexible Display Design
The 3.5-inch high-resolution display rotates 140° vertically and 270° horizontally, allowing clinicians to position the screen for optimal viewing and improved procedural ergonomics.
Integrated Documentation Capabilities
One-touch snapshot and video recording functions allow clinicians to capture airway images and procedures for documentation, training, and quality improvement initiatives.
Anti-Fog Lens Technology
The rapidly heating anti-fog lens helps prevent clouding caused by moisture and secretions, allowing clinicians to maintain uninterrupted visualization throughout the procedure.
Comprehensive Blade Options
ClearViz offers multiple single-use and channeled blade options to support a wide range of patient anatomies and airway management scenarios.
Why ClearViz Video Laryngoscope?
Improved Visualization for More Confident Intubation
ClearViz combines high-resolution imaging with powerful LED illumination to provide clinicians with a clear view of the airway. Enhanced visualization supports improved first-pass intubation success and helps reduce complications during airway procedures.
Designed for Reliable Performance in Challenging Conditions
The anti-fog lens with rapid heating technology helps maintain a clear image despite moisture and secretions, allowing clinicians to continue procedures without delays caused by lens obstruction.
Supports Better Training, Documentation, and Collaboration
With one-touch image capture, video recording, and built-in storage, ClearViz enables clinicians to document procedures, support team training, and improve communication across care teams.
Clinical Applications
Technical Specifications
| Feature/Metric | Specification Details | |
| Processor | Screen size | 3.5 inch |
| Screen ratio | 4:3 | |
| Screen type | TFT-LCD | |
| Resolution | 640 x 480 px | |
| Rotation | Up/down 0-140°, Left/right 0-270° | |
| Memory | Built-in SD card standard 32GB | |
| Connectivity | Micro-USB, Wi-Fi | |
| Camera | Resolution | 2.0M px |
| Field Angle | 66° | |
| Illuminance | LED≥400 lx, h=30mm | |
| Battery | Battery Capacity | 3200mAh lithium-ion battery |
| Working Time | ≥120 minutes | |
| Battery Life Cycle | ≥300 times | |
| Charging Times | 4-6 hours | |
| Blade | Material | medical PC material imported from Bayer Germany |
| Size | Mac 1/2/3/4/5; CMac3/4/5 | |
